Y31160CNC6
Large CNC hobbing machine
The machine tool is suitable for gear processing in heavy truck, wind power, engineering machinery, ship, hoisting, mining machinery, power generation equipment and other industries.
CategoryHobbing Machine
Detail
Main performance and characteristics of machine tool:
◆ the machine tool is a six axis four linkage large CNC hobbing machine.
◆ the machine tool adopts the vertical layout of fixed worktable and moving column to complete radial feed. The machine tool has fully enclosed shield, oil mist collection device and automatic chip removal device.
◆ hob spindle adopts high-precision gear transmission, and worktable adopts double worm gear transmission.
◆ the machine tool is suitable for efficient machining of high-speed coated hobs and cemented carbide blade hobs.
Main technical specifications and parameters of machine tool:
|
Serial number |
Main technical specifications |
Parameter specification |
|
|---|---|---|---|
|
Y31160CNC6 |
|||
|
1 |
Maximum workpiece diameter |
mm |
1600 |
|
2 |
Maximum workpiece modulus |
mm |
24 |
|
3 |
Maximum return angle of tool holder |
度 |
45 |
|
4 |
Maximum speed of hob spindle |
r/min |
260 |
|
5 |
Maximum speed of worktable |
r/min |
8 |
|
6 |
Maximum tool size (diameter) × Length) |
mm |
φ350×375 |
|
7 |
Maximum axial movement of hob |
mm |
300 |
|
8 |
Distance between hob center and worktable rotation center |
mm |
100-1000 |
|
9 |
Distance from hob center to worktable |
mm |
470-1770 |
|
10 |
Table bearing |
T |
15 |
|
11 |
Main motor power |
KW |
43 |
